Product Details
Place of Origin: China
Brand Name: yangft
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiable
Delivery Time: 10 DAYS
Payment Terms: Western Union, MoneyGram, T/T
2000-4000 kg3000 mm19-20 km/h2410-2610 mmMaterial handling tasks in warehouses, logistics centers and delivery centers.
| Model | |||||||||
| Characteristics | Power | Battery | |||||||
| Capacity | kg | 2000 | 2500 | 3000 | 3500 | 4000 | |||
| Load Centre | mm | 500 | 500 | 500 | 500 | 500 | |||
| Lift Height | h | mm | 3000 | 3000 | 3000 | 3000 | 3000 | ||
| Min. Turning Radius | Wa | mm | 2410 | 2410 | 2450 | 2410 | 2850 | ||
| Performance | Travel Speed | Load | km/h | 20 | 20 | 20 | 20 | 19 | |
| Lift Speed | Load | mm/s | 450 | 450 | 450 | 450 | 400 | ||
| Dimensions | Total Length | Without fork | L2 | mm | 2700 | 2700 | 2700 | 2700 | 2985 |
| Total Width | b | mm | 1160 | 1160 | 1225 | 1225 | 1360 | ||
| Max. Lifting Height | h4 | mm | 4245 | 4245 | 4265 | 4265 | 4315 | ||
| Mast Height | h1 | mm | 2070 | 2100 | 2115 | 2115 | 2195 | ||
| Chassis | Tyre | Front | 7.00-12-12PR | 7.00-12-12PR | 28*9-15-12PR | 28*9-15-12PR | 250-15-20PR | ||
| Rear | 6.00-9-10PR | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | 7.00-12-12PR | ||||
| Wheelbase | L2 | mm | 1700 | 1700 | 1700 | 1700 | 1860 | ||
| Service Weight | No load | kg | 3550 | 3750 | 4260 | 4550 | 5050 | ||
| Power | Battery | Electric tension | V | 76.8 | 76.8 | 76.8 | 76.8 | 76.8 | |
| Capacity | Ah | 175 | 205 | 230 | 230 | 300 | |||
| Motor | Drive motor | kW | 10 | 10 | 10 | 10 | 13 | ||
| Oil pump motor | kW | 12 | 12 | 12 | 12 | 14 | |||
